500Mesin Swaging Tali Dawai Tan

Muatkan kapasiti: 500MT, 650MT, 800MT, 1000MT, 1600MT, Dll.

Keluli aloi tuangan, kekuatan tinggi

Kategori: Katil Ujian Tegangan Mendatar

Keterangan
Video
Siasatan

500Mesin Swaging Tali Dawai Tan

Pengenalan
GT Series Wire Rope Swaging Machine is our new generation product.

It has compact form, good looking appearance, and it is easy to operate.

The completed wire rope sling has advantage of high-intensity.

Features:

It’s built in high strength alloy steel, high working stiffness.
High and low pressure pump oil system makes piston upwards and downwards fast, improves the working efficiency.
Strong corrosion resistance, saving wire rope cost
Ensure exact length
An emergency stop button, quickly stop working.
The dies are made of high quality die steel and undergo high temperature heat treatment, quenching, tempering, etc process, which makes them sturdy and durable.

Model and Specification:

Model No. Spesifikasi	GT-300	GT-500	GT-650	GT-800
Max. pressure capacity (MT)	300	500	650	800
Aluminum ferrules (one /multi-stage)	Φ24 /Φ32	Φ32 /Φ42	Φ38 /Φ48	Φ42 /Φ52
Power (KW)	2.2	4	5.5	7.5
Max. oil pressure (Mpa)	56	56	56	56
Max. strok omboh (Mm)	80	100	160	180
Loaded speed (mm/sec)	5	5	5	5
Unloaded piston (mm/sec)	8	8	8	8
Dimension (L×W×H, Mm)	1200×600×1300	1500×610×1600	1650×650×1600	1800×700×1700
Net weight (Kg)	900	1500	2500	3500

Untuk maklumat lanjut, sila hubungi kami: info@victorytest.com
