300J 디지털 디스플레이 샤르피 충격 시험기

금속 재료 샤르피 충격 시험기

제어 모드: 디지털 미터

임팩트 엔저베리: 300J, 500J

테스트 표준: ASTM E23, ISO148 인증, 등

카테고리:
  • 묘사
  • 비디오
  • 문의

JBS Series Digital Display Charpy Impact Testing Machine

(digital display, full protect cover, 300J-500J)

1. 신청 & 기능:

They are mainly used to determine the anti-impact capability of metal materials under dynamic load. They are the best testing equipments for many metal material manufactories, quality inspection departments and universities. The results will be displayed on both digital screen and dial gauge. JBS series impact testers can use pendulum’s residual impact energy to achieve the re-raising of pendulum, so as to save energy. The results can be printed out, be applicable for mass testing departments.

2.표준:

JBS series impact testers are strictly designed according to the standards ASTM E23, ISO148-2006 and GB/T3038-2002, GB/229-2007.

3.주요 기술 명세:

사양JBS-300BJBS-500B
충격 에너지 (J)150,300250,500
Impact velocity (m/s)5.25.4
Raised angle150º
Standard span (밀리미터)40
Distance between pendulum rotating center and specimen center (밀리미터)750
Round angle of jaws (밀리미터)R1-1.5
Round angle of striking edge (밀리미터)R2-2.5 (R8 is optional)
Size of specimen (밀리미터)10 x 10 x 55
전원 공급 장치3phs, 380V, 50Hz/60Hz or specified by users
Dimensions (밀리미터)2124x600x13402144x736x1390
Net Weight (킬로그램)450650
전시LCD Monitor

Besides charpy impact testing machine, we also have 노치 브로칭 기계 (V-노치), 저온 챔버 (-30C, -60C, -80C, -100C, -196C).

자세한 정보, 문의하시기 바랍니다:

이메일: sales@victorytest.com

담당자: 다윗- 승리 테스트

휴대폰 & 왓츠앱: +86-15905419218

Video for ASTM E23 ISO 148 Charpy Pendulum Impact Test Machine

VTS Charpy V Notch Pendulum Impact Test Machine Astm e 23 Iso 148 ASTM A 370

ASTM의 E 23 .ISO 148 Electric Notch Broaching Machine Charpy Pendulum Impact Test Machine

ASTM의 E 23 .ISO 148 Cooling Chamber Charpy Pendulum Impact Test-Machine

ASTM의 E 23 .ISO 148 Charpy V Notch Projector Charpy Pendulum Impact Test Machine
